Veterinary LCD Touch Screen Energy Platform WMV630F
NEW PRODUCT! WMV630F LCD Touchscreen Electrosurgical Unit
The WMV630F satisfies the veterinarian's demands with precision, safety,and reliability.
PRODUCT DETAILS
Main Feature
- Glass full version design, which is extremely tense and beautiful
- Color touch screen operation panel, flexible and easy to operate
- 7 Working modes (5 monopolar working modes, and 2 bipolar working modes)
- Large blood vessel sealing function
- Electrosurgical Pens and Foot Switch Control
- Recently Mode, Power and Other Parameters
- Quick Adjustment of Power
- Cut and Coag in an Intermittent Manner
Product Specifications
Mode | Max Output Power(W) | Load Impedance(n2) | Modulation Frequency(kHz) | Max Output Voltage (V) | Crest Factor | ||
Monopolar | Cut | Pure Cut | 100 | 500 | -- | 1300 | 1.8 |
Blend 1 | 100 | 500 | 20 | 1400 | 2.0 | ||
Blend 2 | 100 | 500 | 20 | 1300 | 2.0 | ||
Coag | Spray | 90 | 500 | 12-24 | 4800 | 6.3 | |
Forced | 60 | 500 | 25 | 4800 | 6.2 | ||
Bipolar | Vessel Sealing | -- | 100 | 20 | 700 | 1.9 | |
Standard | 60 | 100 | 20 | 700 | 1.9 | ||
Ordering Information
Model | Description | |
WMV630F |
| Electrosurgical Unit |
JBW-200 |
| Monopolar Foot-Switch |
JBW-100 |
| Bipolar Foot-Switch |
HX-(B1)S |
| Hand-Switch Pencil, Disposable |
38813 |
| Patient Return Electrode Rods(10mm) With Cable, Reusable |
HX-(D)P |
| Bipolar Forceps, Reusable, Connecting Cable |
SM1150 |
| 5mm,37cm Length Laparoscopic Instrument Straight Tip |
