Veterinary High Cost-Effective Energy Platform WMV630E
Capable of most monopolar and bipolar surgical procedures and packed withdependable safety features, the WMV630E satisfies the veterinarian's demands with precision, safety, and reliability.
PRODUCT DETAILS
Main Feature
- 3 Monopolar Cut: Pure Cut, Blend 1, Blend 2
- 2 Coag: Spray, Forced,
- 1 Bipolar Output: Vessel Sealing(Provide exceptional coagulation and transection of vessels up to 7mm in diameter.)
- CQM Contact Quality Monitoring System
- Electrosurgical Pens and Foot Switch Control
- Recently Mode, Power and Other Parameters
- Quick Adjustment of Power and Volume
- Cut and Coag in an Intermittent Manner
Product Specifications
Mode | Max Output Power(W) | Load Impedance(n2) | Modulation Frequency(kHz) | Max Output Voltage (V) | Crest Factor | ||
Monopolar | Cut | Pure Cut | 100 | 500 | -- | 1300 | 1.8 |
Blend 1 | 100 | 500 | 20 | 1400 | 2.0 | ||
Blend 2 | 100 | 500 | 20 | 1300 | 2.0 | ||
Coag | Spray | 90 | 500 | 12-24 | 4800 | 6.3 | |
Forced | 60 | 500 | 25 | 4800 | 6.2 | ||
Bipolar | Standard | -- | 100 | 20 | 700 | 1.9 | |
Ordering Information
Model | Description | |
WMV630E |
| Electrosurgical Unit |
JBW-200 |
| Monopolar Foot-Switch |
HX-(B1)S |
| Hand-Switch Pencil, Disposable |
38813 |
| Patient Return Electrode Rods(10mm)With Cable, Reusable |
HX-(D)P |
| 5mm,37cm Length Laparoscopic Instrument Straight Tip |
