Auto Hematology Analyzer

Comprehensive Solution

Ali-in-one machine

10.4inch touch screen, no need extra PC, built-in barcode scanner(optional), built-in thermal printer

Cost-effective

3 reagents (2 Lyses, 1 Diluent) only, less consumption 60 samples per hour, minimize your workload

Better human-machine interaction

Provide 25 parameters with 4 scattergrams and 2 histograms

User-friendly desighed software, store 60,000 results,

Real-time monitoring reagent, voltage, temperature status

Intelligent software menu for hardware diagnosis

Advanced high voltage and flush to remove blockage automatically

Accurate results, easy maintenance

Long life semi-conductor laser to differentiate WBC into 5 parts Ceramic syringe to

Types:

IVT-VH30: 24 parameters + 3 histograms, 9μL sample volume, supports 19 species, throughput unmarked.

IVT-420A VET: 20 parameters + 3 histograms, 35 samples/h, 8-inch touch screen, 1 channel.

IVT-420B/C VET: 60 samples/h, 2 channels; 420C is equipped with a 10.4-inch touch screen, 420B with an 8-inch one.

Core principle: Impedance for cell counting, 3-part WBC differentiation (Granulocytes, lymphocytes, midcells).

IVT-VH40l: 26 parameters + EOS histogram, 4-part WBC differentiation (neutrophils, lymphocytes, monocytes, eosinophils), supports 19 species, optimized for low WBC/PLT samples.

Reagent room design for space saving, new lyse formula with higher accuracy.

IVT-420D VET: 25 parameters + 4 scattergrams + 2 histograms, 60 samples/h, semiconductor laser for 5-part WBC differentiation.

Ceramic syringe, automatic blockage removal, stores 60,000 results, optional built-in barcode scanner.

All analyzers are specially designed for veterinary use, supporting common animal species such as canine and feline, with some models compatible with additional species like bovine, equine, and porcine. They feature human-computer interaction interfaces (LCD/touch screen) and common external interfaces (USB/RS232), with some supporting LIS for data transmission. The power supply of all analyzers is compatible with AC 100~240V, 50/60Hz, adapting to different regional power grids. All analyzers support automatic/manual calibration modes to ensure test result accuracy and include quality control (QC) functions.

Performance
